SPEED LOG


SAL R1A
- Speed Log
Product description


  • The SAL R1a is an IMO type-approved speed log for measuring
    longitudinal speed through water (STW), based on proven Acoustic
    Correlation technology.

  • The speed log is designed to meet requirements as specified by
    authorities and ship owners, with performance exceeding applicable
    IMO specifications.

  • Its closed-ended installation is simple and cost-effective, with no need
    for a watertight compartment or piping above the waterline.

  • Pressure tested and approved according to PN16 (24 bar, 240 m)

  • Complies with IMO resolution A.824(19)

Product brochure

SKIPPER EML224 Compact
- Speed Log
Product description


  • The SKIPPER EML224 Compact is the Electromagnetic Speed Log
    available in single or dual axis, making it more flexible depending on
    customers needs and demands.

  • Water speed in single or dual axis

  • Compact Display 144x144 mm

  • Sea Temperature readout

  • NMEA 0183 and Analog pulses output

  • 1 Programmable contact closure

Product brochure

SKIPPER DL1
- Doppler Speed Log
Product description


  • The SKIPPER DL1 is a Single Axis Speed Log, working on the
    doppler principle, providing longitudinal ship’s speed (STW) and
    distance relative to sea water. The SKIPPER DL1 gives accurate
    navigation parameters, measured as they happen, and presented in
    a logical, user friendly way.

  • Single Axis Doppler Speed Log

  • Water speed (STW) in Single Axis

  • Display in 28 x 30 LED dot matrix with full night dimming

  • Sea Temperature readout

  • NMEA 0183 output

  • 3 userfriendly programmable displays and integrated menus

  • Fully automatic settings

Product brochure

SKIPPER DL1 MULTI
- Doppler Speed Log
Product description


  • The SKIPPER DL1 Multi is a Single Axis Doppler Speed Log, working
    on the doppler principle, providing longitudinal ship’s speed (STW)
    and distance relative to sea water. The SKIPPER DL1 Multi gives
    accurate navigation parameters measured as they happen and
    presented in a logical, user friendly way.

  • Single Axis Doppler Speed Log

  • Water Speed in Single Axis

  • Compact Display in 28 x 30 LED dot matrix with full night dimming

  • Sea temperature

  • LAN and NMEA 0183 output

  • 3 user friendly programmable displays and integrated menus

  • Fully automatic settings

Product brochure

SKIPPER DL2
- Doppler Speed Log
Product description


  • The SKIPPER DL2 is a Dual Axis Doppler Speed Log, working on the
    doppler principle, providing longitudinal and transversal ship’s speed
    (STW and SOG) and distance relative to sea water. The SKIPPER
    DL2 gives accurate navigation parameters, measured as they happen,
    and presented in a logical, user friendly way.

  • Dual Axis Doppler Speed Log

  • Water speed in dual axis (STW)

  • Ground speed in dual axis (SOG)

  • Docking functionality as standard (Three axis in STW and SOG)

  • 9" Touch Display

  • Sea Temperature readout

  • LAN and NMEA 0183 output

  • User friendly programmable displays and integrated menus

  • Fully automatic settings

  • Resultant Sea Current in speed and direction

Product brochure

SKIPPER DL21
- Doppler Speed Log
Product description


  • The SKIPPER DL21 is a Dual Axis Doppler Speed Log and a Single
    Axis Doppler Speed Log in one sensor unit. It is working on the
    doppler principle, providing longitudinal and transversal ship’s speed
    (STW and SOG) and distance relative to sea water. The DL21 Speed
    Log is designed for ships over 50.000 GT with simultaneous and
    independent measurement of speed through water and speed over
    ground. This is according to new IMO resolution MSC334(90).

  • Dual Axis Doppler Speed Log

  • Independent Single Axis Doppler Speed Log

  • Water speed in single and dual axis (STW)

  • Ground speed in dual axis (SOG)

  • Docking functionality as standard (Three axis in STW and SOG)

  • 9" Touch Display

  • Sea Temperature readout

  • LAN and NMEA 0183 output

  • User friendly programmable displays and integrated menus

  • Fully automatic settings

  • Resultant Sea Current in speed and direction

Product brochure

SKIPPER SD21
- Combined Speed Log
Product description


  • The SKIPPER combined speed log SD21 is a three axis speed log
    and a one axis speed log providing both SOG and STW. It is providing
    longitudinal and fore/aft transversal ship speed over ground (SOG) in
    additional to longitudinal speed through water (STW). The SKIPPER
    combined speed log SD21 provides accurate navigation parameters
    measured as they happen, and presented in a logical, user friendly
    way.

  • Speed over ground (SOG) in three axis (Docking mode)

  • Speed through water (STW) in one axis

  • Colour 9" touch screen with day/night screens and Compact dot LED display

  • NMEA 0183 output

  • LAN

  • GPS, GLONASS (SOG) and Doppler speed (STW)

Product brochure

SKIPPER SL1200
- Satellite Speed Log
Product description


  • The SKIPPER SATLOG SL1200 is a three axis speed log. It is
    providing longitudinal and fore/aft transversal ship speed over ground
    (SOG). The SKIPPER SATLOG SL1200 provides accurate navigation
    parameters measured as they happen, and presented in a logical,
    user friendly way.

  • Speed over ground (SOG) in three axis (Docking mode)

  • Colour 9" touch screen with day/night screens

  • NMEA 0183 output

  • GPS and GLONASS Speed

Product brochure
