GYROCOMPASS / GPS COMPASS / FLUXGATE COMPASS |
|
|
Simrad GC80 / GC85
Gyrocompass |
Product description |
 |
-
The Simrad GC80/GC85 are fully IMO type approved gyrocompasses
for
standard
vessels (GC80) and High Speed Craft (GC85)..
-
The unique technology in the gyrocompass eliminates the need for
annual
service.
The highest possible accuracy and stability is
provided by
a
sophisticated and fully
sealed sensitive element.
-
The Simrad GC80 and GC85 gyrocompasses are available with
Compact,
Dual or
Expanded control units for installation as part of a
single- or
multi-gyro system.
-
Easily incorporated into new vessels or retrofits, the GC80 and GC85
suit
a variety of
applications from navigation for merchant vessels to
dynamic
positioning for OSVs.
|
Simrad HS80A GNSS Compass /
MX575D D/GNSS Compass
|
Product description |
|
-
The Simrad HS80A GNSS and MX575D D/GNSS compasses
are
designed
to provide
reliable heading, ROT and position information
to
other navigation
systems.
-
Both models are IMO Type-Approved as a primary positioning and
heading
device
when used with Simrad Control Display Unit P3007.
-
The HS80A delivers heading accuracy of better than 0.5° and provide
sub-meter
DGPS
positioning accuracy. This level of accuracy is
achieved in the HS80A
from SBAS.
The HS80A is supplied with
NMEA 2000 as the standard interface,
but can be used as
a NMEA
0183 device with an optional cable.
-
The MX575D delivers heading accuracy of better than 0.5° and provide
sub-meter DGPS
positioning accuracy. This level of accuracy is
achieved
in
the MX575D by using
the RTCM correction data supplied
from its internal
beacon
demodulator or from SBAS.
The standard
interface on the MX575D
is
NMEA 0183, but can also be used as
NMEA 2000 device with an optional
adaptor.
|
Simrad HS75 GNSS Compass
|
Product description |
 |
-
The Simrad HS75 GNSS supports GPS, GLONASS, BeiDou, Galileo,
and
QZSS
for pinpoint global positioning and heading accuracy.
-
The commercial-grade HS75 offers heading accuracy to within 0.75
degrees:
much
greater than a common magnetic rate compass,
without the cost and
maintenance
of a gyrocompass.
-
The HS75 also calculates Rate of turn, Heave, Pitch, and Roll. Rate of
turn
is essential
for optimal autopilot performance, while Heave data is
used by
some sonar equipment
to compensate for the effects of wave
action. This
additional data is output to compatible
equipment over
NMEA 2000® network.
|
ComNav G2 & G2B GNSS Compass
|
Product description |
 |
-
The ComNav G2 & G2B GNSS Compas supports both GPS and GLONASS
satellites
for complete redundancy.
-
Heading accuracy to within 0.25 degrees rms and position accuracy
under 0.3m
95% confidence (DGPS).
-
Pre-programmed default settings for Heading, Rate of Turn, Course over Ground,
Lat/Long position, Time & Date.
-
IMO Compliant with G3 color display.
-
Fully compatible with on board NMEA 0183 and NMEA 2000® RADAR,
ECDIS, AIS, Cameras, SONAR, PC and Autopilots
|
ComNav G1 GNSS Compass
|
Product description |
 |
-
The ComNav G1 GNSS Compas supports both GPS and GLONASS
satellites
for complete redundancy.
-
Heading accuracy to within 0.5 degrees rms and position accuracy
under 1.0m
95% confidence (DGPS).
-
Pre-programmed default settings for Heading, Rate of Turn, Course over Ground,
Lat/Long position, Time & Date.
-
Optional G3 color display system.
-
Fully compatible with on board NMEA 0183 and NMEA 2000® RADAR,
ECDIS, AIS, Cameras, SONAR, PC and Autopilots
|
Simrad Precision-9 Compass
|
Product description |
 |
-
The Precision-9 Compass is designed to supply heading and
rate-of-turn
information to Simrad autopilot, radar and navigation
systems aboard
non-SOLAS
vessels.
-
Incorporating a nine-axis array of solid-state motion and orientation
sensors,
the Precision-9 also provides accurate pitch and roll data to
compatible
equipment
via its NMEA 2000® interface.
-
An adjustable mounting bracket and single-cable connection allow
simple
and
cost-effective installation aboard any vessel, including an
up-mast
mounting option
suitable for steel hulls.
|
|
